Connectable Device Lists Appendix A
Crimp Terminals for Communications Cables
Screwdrivers for Connector Set Screws
Terminating Resistors
In addition to the Terminating Resistors listed above, the trunk line can be terminated by installing a Terminat-
ing Resistor (included with the Tap) into the socket of a T-branch Tap or Power Supply Tap.
Model Crimping tool Specifications Remarks
AI Series
AI 0.25-6YE: For thin cable signal lines
AI 0.5-6WH: For thin cable power lines
AI 0.25-8YE: For thin cable signal lines
AI 0.5-10WH: For thin cable power lines
A1-6: For thick cable signal lines
AI 2.5-8BU: For thick cable power lines
A1-10: For thick cable signal lines
AI 2.5-10BU: For thick cable power lines
CRIMPFOX ZA3 For a single wire PHOENIX CON-
TACT
AI Series
AI TWIN2 × 0.5-8WH (for thin cable)
CRIMPFOX
UD6 or CRIMP-
FOX ZA3
For two wires (multi-
drop)
H0.5/16.5 ZH For two wires (multi-
drop)
Weidmuller
Model Specifications Manufacturer
XW4Z-00C Screw driver for DeviceNet connectors OMRON
SZF-1 Screw driver for DeviceNet connectors PHOENIX CONTACT
Model Specifications
DRS1-T Terminal-block Terminating Resistor (121 Ω ±1%, 1/4 W)
DRS2-1 Shielded Micro-size (M12) Connector with Terminating Resistance (male plug)
DRS2-2 Shielded Micro-size (M12) Connector with Terminating Resistance (female socket)
DRS3-1 Shielded Mini-size Connector with Terminating Resistance (male plug)
DCN4-TM4 Connector-type Terminating Resistor for Flat Cable, 121 Ω
DCN4-TP4D Flat Cable Power Supply Terminal Block with Terminating Resistance (for Flat Cable), 121 Ω
