113
Connectable Device Lists Appendix A
T- b r a n c h Ta p s
Single-branch Taps
Three-branch Taps
Shielded T-branch Connectors
Model Specifications
DCN1-1NC Three Straight Clamp Connectors with attachment screws (model XW4G-05C1-H1-D) are included
with the DCN1-1NC. (The DCN1-1NC can make one branch.)
The connector insertion direction is vertical.
A Terminating Resistor (included) can be connected.
DCN1-1C Three Straight Connectors with attachment screws (model XW4B-05C1-H1-D) are included with
the DCN1-1C. (The DCN1-1C can make one branch.)
The connector insertion direction is horizontal.
A Terminating Resistor (included) can be connected.
DCN1-2C Three Straight Connectors with attachment screws (model XW4B-05C1-H1-D) are included with
the DCN1-2C. (The DCN1-2C can make one branch.)
The connector insertion direction is vertical.
A Terminating Resistor (included) can be connected.
DCN1-2R Three Right-angle Connectors with attachment screws (model XW4B-05C1-VIR-D) are included
with the DCN1-2R. (The DCN1-2R can make one branch.)
The connector insertion direction is vertical.
A Terminating Resistor (included) can be connected.
Model Specifications
DCN1-3NC Five straight clamp connectors with attachment screws (model XW4G-05C1-H1-D) are included
with the DCN1-3NC. (The DCN1-3NC can make three branches.)
The connector insertion direction is vertical.
A Terminating Resistor (included) can be connected.
DCN1-3C Five straight connectors with attachment screws (model XW4B-05C1-H1-D) are included with the
DCN1-3C. (The DCN1-3C can make three branches.)
The connector insertion direction is horizontal.
A Terminating Resistor (included) can be connected.
DCN1-4C Five straight connectors with attachment screws (model XW4B-05C1-H1-D) are included with the
DCN1-4C. (The DCN1-4C can make three branches.)
The connector insertion direction is vertical.
A Terminating Resistor (included) can be connected.
DCN1-4R Five right-angle connectors with attachment screws (model XW4B-05C1-VIR-D) are included with
the DCN1-4R. (The DCN1-4R can make three branches.)
The connector insertion direction is vertical.
A Terminating Resistor (included) can be connected.
Model Specifications
DCN2-1 Shielded T-branch Connector (1 branch) with 3 micro-size (M12) connectors
DCN3-11 Shielded T-branch Connector (1 branch) with 3 mini-size connectors
DCN3-12 Shielded T-branch Connector (1 branch) with 2 mini-size connectors and 1 micro-size (M12) con-
nector
