114
Connectable Device Lists Appendix A
Flat Cable Connectors
Power Supply Tap
Cable Connectors for Sensor Terminals
Cable Connectors for Environment-resistive Slaves
The following cable connectors for Environment-resistive Slaves cannot be used for DeviceNet communica-
tions because of differences such as the number of pins that are used.
For DRT1-@D@@C(-1) Slaves
Model Specifications
DCN4-TR4-1 Flat connector socket for flat cable
DCN4-BR4 Flat connector plug for flat cable
DCN4-BR4D Thin Cable-Flat Cable conversion connector.
Used to branch to thin cable.
Model Specifications
DCN1-1P The DCN1-1P is used to connect the communications power supply to the network.
Includes two XW4B-05C1-H1-D Straight Connectors with attachment screws, a terminator, and
two fuses.
A Terminating Resistor (included) can be connected.
Model Specifications
XS8A-0441 Connector marking: XS8-1
Applicable cable wire size: 0.3 to 0.5 mm
2
XS8A-0442 Connector marking: XS8-2
Applicable cable wire size: 0.14 to 0.2 mm
2
Connector type Model Specifications
I/O connectors XS2G-D4@@ Shielded, micro-size (M12) male plug connector for custom cable
assembly (crimp or solder)
XS2H-D421-@@@ Cable with shielded, micro-size (M12) male plug connector on one
end and loose wires on the other
XS2W-D42@-@@@ Cable with shielded, micro-size (M12) connectors on both ends
(male plug on one end and female socket on the other)
External power sup-
ply connectors
XS2C-D4@@ Shielded, micro-size (M12) female socket connector for custom
cable assembly (crimp or solder)
XS2F-D42@-@80-A Cable with shielded, micro-size (M12) female socket connector on
one end and loose wires on the other
