123
Dimensions of Connectable Devices Appendix B
DCN1-1C T-branch Tap (Single Branch)
DCN1-2C and DCN1-2R T-branch Taps (Single Branches)
97±0.3
90
14±0.3
15.5
DCN1-1
T-PORT TAP
45
97
7
15.5
21
31
Mounting holes or taps
Two, 3.5 dia. or M3
All dimensions are in mm.
97±0.3
90
14±0.3
15.5
DCN1-2
T-PORT TAP
45
97
7
15.5
21
31
Two, 3.5 dia. or M3
Mounting holes or taps
All dimensions are in mm.
