Omron E5AN-H

187
Operation Level Section 5-3
These parameters independently set the alarm value upper and lower limits
when the mode for setting the upper and lower limits is selected for the Alarm
1 Type parameter (initial setting level).
• This parameter sets the upper and lower limit values of alarm 1.
• During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the Decimal
Point parameter setting.
• The set value is saved in the Alarm Value Upper Limit 1 and Alarm Value
Lower Limit 1 parameters in the current bank.
■ Related Parameters
Input type: Page 224, Scaling upper limit, Scaling lower limit, Decimal point:
Page 226, Alarm 1 type: Page 231 (initial setting level), Standby sequence
reset: Page 244, Auxiliary output * open in alarm: Page 245, Alarm 1 hystere-
sis: Page 233, Alarm 1 latch: Page 250 (advanced function setting level)
Bank * alarm value upper limit 1, Bank * alarm value lower limit 1 (bank setting
level): Page 212
These parameters independently set the alarm value upper and lower limits
when the mode for setting the upper and lower limits is selected for the Alarm
2 Type parameter (initial setting level).
• This parameter sets the upper and lower limit values of alarm 2.
• During temperature input, the decimal point position depends on the cur-
rently selected sensor, and during analog input it depends on the Decimal
Point parameter setting.
• The set value is saved in the Alarm Value Upper Limit 2 and Alarm Value
Lower Limit 2 parameters in the current bank.
al1h Alarm Value Upper Limit 1
Alarm 1 must be assigned.
The alarm 1 type must not be 1, 4, or
5.
al1l Alarm Value Lower Limit 1
Setting range Unit Default
−19999 to 32400 EU 0.0
Function
Setting
See
See
al2h Alarm Value Upper Limit 2
Alarm 2 must be assigned.
The alarm 2 type must not be 1, 4, or
5.
al2l Alarm Value Lower Limit 2
Setting range Unit Default
−1999 to 9999 EU 0
Function
Setting
