8.11 Control initial setting 2 level (l.2)
8-51
Setting data
• Use these settings to enable or disable extraction of square root
operations for each input.
● Related setting data
"Extraction of square root
∗
Low-cut point" (Adjustment level 2) (P.8-24)
• Use these settings to enable or disable straight-line approximation.
● Related setting data
"Straight-line approximation
∗ input 1", "Straight-line approximation
∗ input 2", "Straight-line approximation ∗ output 1", "Straight-line
approximation
∗ output 2" (Approximation setting level) (P.8-33)
• Use this setting to enable or disable broken-line approximation for
input 1.
Extraction of square root 1 enable
Extraction of square root 2 enable
sqr.1
sqr.2
Extraction of square root 3 enable
Extraction of square root 4 enable
sqr.3
sqr.4
l.2
Function
Setting
Setting range Units Default value
off: Disable
on : Enable
− off
Reference
Reference
Straight-line approximation 1 enable
Straight-line approximation 2 enable
scl.1
scl.2
Proportional control
l.2
Function
Setting
Setting range Units Default value
off: Disable
on : Enable
− off
Reference
Reference
Broken-line approximation 1 enable
fnc.1
l.2
Function
Setting
Setting range Units Default value
off: Disable
on : Enable
− off
