1.3 Input/output Configuration and Main Functions
1-11
Overview
When used for transfer output type, assign the data to be transferred to
an unused output.
For outputs supporting multi-output, specify pulse voltage output or
linear current output according to the multi-output output type.
For linear current output, 0 to 20 mA or 4 to 20 mA can be selected.
Pulse voltage output is 12 V DC, 40 mA.
● Auxiliary output
assignments
Use this setting to assign what type of data is output from each
auxiliary output.
For the multi-point input type, assignment data can be set for channels
2 and higher as needed for the number of channels. The U-ALM output
is an OR output with alarm functions 1 to 4 for all channels.
OUT1
OUT2
OUT3
OUT4
Output
Multi-output output type
Pulse voltage output
Linear current output
0 - 20 mA
4 - 20 mA
Linear current output output type
Channel 4 alarm 1
Channel 4 alarm 2
Channel 4 alarm 3
Channel 4 alarm 4
Channel 4 input error
Channel 4
Channel 3 alarm 1
Channel 3 alarm 2
Channel 3 alarm 3
Channel 3 alarm 4
Channel 3
Channel 2 alarm 1
Channel 2 alarm 2
Channel 2 alarm 3
Channel 2 alarm 4
Channel 2 input error
Channel 2
SUB1
SUB2
SUB3
SUB4
Auxiliary output
Auxiliary output assignment
Channel 1 alarm 1
Channel 1 alarm 2
Channel 1 alarm 3
Channel 1 alarm 4
Channel 1 input error
Channel 1 RSP input error
U-ALM output
Channel 1
All-channel alarm 1 OR output
All-channel alarm 2 OR output
All-channel alarm 3 OR output
All-channel alarm 4 OR output
All-channel input error OR output
All-channel RSP input error OR output
All Channels
