Omron E5AR - MANUAL 2 User Manual

4.4 Setting the input type
4-9
Settings Required
for Basic Control
Set the input type switch according to the "Input type" setting.
The initial settings are "2" and "TC.PT".
■ Scaling Setting the display to show 0.0 for an input value of 5 mA and 100.0 for
20 mA when the input 1 type is set to "4 to 20 mA".
1. Hold the L key down for at least 3 seconds to move from "RUN level" to
"Input initial setting level".
2. Make sure that "i1-t: Input 1 input type" is "15: 4 to 20 mA".
3. Press the M key repeatedly to select "inp.1: Scaling input value 1".
Set to “5” with the UD keys.
4. Press the M key to select "dsp.1: Scaling display value 1".
Set to “0” with the UD keys.
5. Press the M key to select "inp.2: Scaling input value 2".
Set to “20” with the UD keys.
6. Press the M key to select "dsp.2: Scaling display value 2".
Set to “1000” with the UD keys.
15 4 to 20 mA One of the following ranges is displayed depending
on the scaling
-19999 to 99999
-1999.9 to 9999.9
-199.99 to 999.99
-19.999 to 99.999
-1.9999 to 9.9999
ANALOG
16 0 to 20 mA
17 1 to 5 V
18 0 to 5 V
19 0 to 10 V
Set value Input type
Setting range
Input type
switch
(°C) (°F)
TC.PT
IN1
TYPE
ANALOG
When analog input (voltage input, current input) is used,
scaling according to the type of control is possible.
Hint
25.0
0.0
0.0
i1-t
15
l.0
inp.1
5
l.0
dsp.1
0
l.0
inp.2
20
l.0
dsp.2
1000
l.0
