Item Description
Camera Performs a test measurement with the camera image.
• : Changes the camera image mode to Through image.
• : Not used.
•
: Not used.
• : Performs a test measurement. The results will be displayed on the image,
detailed results display area, and the Unit list (flow).
•
: Not used.
• : Performs a unit measurement. The results will be displayed on the image
and the detailed results display area.
Files Performs a test measurement on with an image file.
• : Not used.
• : Selects an image file and a reference image for the test measurement.
•
: Select the previous file of the currently selected file and perform a test meas-
urement.
• : Performs a test measurement. The results will be displayed on the image,
detailed results display area, and the Unit list (flow).
•
: Select the next file of the currently selected file and perform a test measure-
ment.
•
: Performs a unit measurement. The results will be displayed on the image
and the detailed results display area.
Registration Registers the displayed image as a reference image.
Display detailed re-
sults
Displays the name and the measurement results of a processing unit selected on the
Unit list (flow). For the processing items related to Camera image input, only the
judgment results of the processing unit is displayed.
*1. Regarding Open the unit setting UI, refer to Setting Properties for Processing Units on page 5 - 25 of
5-5-2 Editing Processing Units in a Scene [TDM Editor] on page 5 - 24.
Additional Information
• In the flow measurement, a measurement is performed with the set flow.
In the unit measurement, a measurement is performed only with the processing unit selected.
• The unit measurement cannot be performed with processing items categorized in image input
related (Input Image).
Additional Information
When the measurement of a processing unit is performed, the overall judgement and the proc-
essing time are displayed up to 8,191-unit under each processing unit name on the Unit list
(flow). When the measurement is performed over 8,291-unit, i.e. with a repeat processing, the
overall judgement and the processing time will not be displayed from 8,192-unit and later.
Scene Variable Tab Screen
A Scene variable holds data such as parameters and measurement results for a processing item,
moreover, which is also used to reference data and/or perform calculations between processing units
in a scene.
5 Creating Measurement Scenes
5 - 19
FH/FHV Series Vision System User’s Manual (Z365-E1)
5-5 Using Variables to Edit the Flow [TDM Editor]
5
5-5-1 Edit Flow Screen

Omron fh series Specifications

General

Type	Machine Vision System
Series	FH Series
Power Supply	24 VDC
Storage Temperature	-20 to 60°C
Humidity	35 to 85% RH (non-condensing)
Image Sensor	CMOS
Processing Speed	High-speed processing
Connectivity	Ethernet
I/O	Digital I/O
Operating System	Embedded OS
I/O Ports	Ethernet, USB
