1 Click the Edit flow tab. Display the Edit flow tab screen.
For more details, refer to Edit Flow Tab Screen on page 5 - 15.
2
On the Edit flow tab screen, select a processing unit on the Unit list (flow) to copy.
3
In the Edit flow button area, click Copy.
Additional Information
The following operation also enables processing units to be copied.
• Click Copy from Edit flow in the Menu bar.
• Right-click a processing unit on the Unit list (flow) and then click Copy on the displayed short-
cut menu.
Copy the selected processing item while holding data and variables being used.
4
On the unit list (flow), select a position to paste.
5
In the Edit flow button area, click Paste
Additional Information
The following operation also enables processing units to be pasted.
• Click Paste from Edit flow in the Menu bar.
• Right-click a processing unit on the Unit list (flow) and then click Paste on the displayed
shortcut menu.
The copied processing unit is inserted to the selected position on the Unit list (flow) while hold-
ing the setting data and variables being used.
Deleting a Processing Unit
Additional Information
When attempting to delete a processing unit number 0, a warning dialog will be displayed.
1 Click the Edit flow tab. Display the Edit flow tab screen.
For more details, refer to Edit Flow Tab Screen on page 5 - 15.
2
On the Edit flow tab screen, select a processing unit on the Unit list (flow) to delete.
3
In the Edit flow button area, click Delete.
Additional Information
The following operation also enables processing units to delete.
• Click Delete from Edit flow in the Menu bar.
• Right-click a processing unit on the Unit list (flow) and then click Delete on the displayed
shortcut menu.
4
The Edit flow dialog is displayed. Click Yes.
5 Creating Measurement Scenes
5 - 28
FH/FHV Series Vision System User’s Manual (Z365-E1)
