Omron FHV Series - Page 55

Dimensions
• FHV7H-□□□□□-C
30.0
36.0
4-M5.0
68.4
126.7
68.5 2.7
36.8 35.0
55.5
65.3
35.5
50.0
98.0
9.2
4-M5.0
110.0
6.0
16.7
12.2
20.5
22.5
69.0
35.5
35.0 35.5
36.0
30.0
5.5dia.
50.0
98.0
5.5dia.
Mounting screw holes (The tolerance: ± 0.1 mm)
OPTICAL AXIS
depth4
depth6
Recommenden tightening torque: 2.3N・m
(Unit: mm)
3 Configuration
3 - 7
FHV Series Smart Camera Setup Manual (Z408-E1)
3-1 Smart Camera
3
3-1-1 FHV Series
