High-resolution Telecentric Lens VS-TCH Series for C Mount Lens
for 2/3-inch Image Sensor
FHV7H-□004, FHV7H-□01, FHV7H-□032, FHV7H-□050, FHV□□-□063R, and FHV□□-□120R are rec-
ommended.
Model
3Z4S-LE VS-TCH05 3Z4S-LE VS-TCH1
-65□□□□ -110□□□□ -65□□□□ -110□□□□
Optical magnification (±5%) 0.5× 1.0×
Field of
view
(±5%)
(VxH)
[mm]
FHV7H-□004/-
□016
1/2.9-inch
equivalent
9.9×7.5 5.0×3.7
FHV7H-□032 1/1.8-inch
equivalent
14.1×10.6 7.1×5.3
FHV7H-□063R 1/1.8-inch
equivalent
14.8×9.8 7.4×4.9
FHV7H-□120R 1/1.7-inch
equivalent
14.8×11.1 7.4×5.6
FHV7H-□50 2/3-inch
equivalent
16.9×14.1 8.5×7.1
WD [mm]
*2
75.3 110.8 68.8 110.3
Effective F No. 9.42 9.49 9.94 10.49
Depth of field [mm]
*3
3 3.04 0.8 0.84
Resolution [μm]
*4
12.43 12.9 6.71 6.99
TV distortion 0.02% 0.02% 0.01% 0.02%
Max. sensor size 2/3-inch
Model
3Z4S-LE VS-TCH1.5 3Z4S-LE VS-TCH2
-65□□□□ -110□□□□ -65□□□□ -110□□□□
Optical magnification (±5%) 1.5× 2.0×
Field of
view
(±5%)
(VxH)
[mm]
FHV7H-□004/-
□016
1/2.9-inch
equivalent
3.3×2.5 2.5×1.9
FHV7H-□032 1/1.8-inch
equivalent
4.7×3.5 3.5×2.7
FHV7H-□063R 1/1.8-inch
equivalent
4.9×3.3 3.7×2.5
FHV7H-□120R 1/1.7-inch
equivalent
4.9×3.7 3.7×2.8
FHV7H-□50 2/3-inch
equivalent
5.6×4.7 4.2×3.5
WD [mm]
*2
65 110.8 65 110.8
Effective F No. 11.8 11.97 13.6 13.5
Depth of field [mm]
*3
0.4 0.43 0.3 0.27
Resolution [μm]
*4
5.24 5.33 4.53 4.53
TV distortion 0.01% 0.02% 0.03% 0.03%
Max. sensor size 2/3-inch
3 Configuration
3 - 27
FHV Series Smart Camera Setup Manual (Z408-E1)
3-4 C Mount Lenses
3
3-4-1 Specifications
