Model
3Z4S-LE VS-TCH4
-65□□□□ -110□□□□
Optical magnification (±5%) 4.0×
Field of
view
(±5%)
(VxH)
[mm]
FHV7H-□004/-
□016
1/2.9-inch equivalent 1.4×0.9
FHV7H-□032 1/1.8-inch equivalent 1.8×1.3
FHV7H-□063R 1/1.8-inch equivalent 1.8×1.2
FHV7H-□120R 1/1.7-inch equivalent 1.9×1.4
FHV7H-□50 2/3-inch equivalent 2.1×1.8
WD [mm]
*2
65 110.8
Effective F No. 17.91 22.2
Depth of field [mm]
*3
0.09 0.11
Resolution [μm]
*4
3 3.73
TV distortion 0.02% 0.03%
Max. sensor size 2/3-inch
*1. Insert the shape into in the model number as follows.
Straight: -O
Coaxial: CO-O
*2. The working distance is from the end of the lens to the sensor.
*3. The depth of field is calculated using a allowable diameter of confusion circle of 0.04 mm.
*4. The resolution is calculated using a wavelength of 550 nm.
Note:
(1) Fixing the lens or other reinforcement may be required depending on the installation angle or op-
erating environment (vibration/shock).
When fixing the lens, insulate the lens from the fixture.
(2) The above specifications are values calculated from the optical design and can vary depending on
installation conditions.
3 Configuration
3 - 28
FHV Series Smart Camera Setup Manual (Z408-E1)
