Non-telecentric Macro Lens VS-MC Series for C Mount Camera
Model
3Z4S-LE VS
-MC01-330 -MC03-180 -MC05-130 -MC1-80
Optical magnification (±5%) 0.1x 0.3x 0.5x 1.0x
Field of view
(±5%)
(VxH)
[mm]
FHV7H-
□004/-□016
1/2.9-inch
equivalent
49.7x37.3 16.6x12.4 9.9x7.5 5.0x3.7
FHV7H-□032 1/1.8-inch
equivalent
70.7x53.0 23.6x17.7 14.1x10.6 7.1x5.3
FHV7H-
□063R
1/1.8-inch
equivalent
73.7x49.2 24.6x16.4 14.8x9.8 7.4x4.9
FHV7H-
□120R
1/1.7-inch
equivalent
74.0x55.5 24.7x18.5 14.8x11.1 7.4x5.6
FHV7H-□050 2/3-inch
equivalent
84.5x70.7 28.2x23.6 16.9x14.1 8.5x7.1
WD [mm]
*1
325.5 184.8 126.3 82.4
Effective F No. 4.43 5.29 6.10 8.14
Resolution [μm]
*2
30.5 11.6 8.2 5.5
Depth of field [mm]
*3
35.4 4.7 2.0 0.7
TV distortion 0.01% or less 0.00% or less 0.00% or less 0.00% or less
*1. The working distance is from the end of the lens to the sensor.
*2. The resolution is calculated using a wavelength of 550 nm.
*3. The depth of field is calculated using an allowable diameter of confusion circle of 0.04 mm.
3 Configuration
3 - 29
FHV Series Smart Camera Setup Manual (Z408-E1)
3-4 C Mount Lenses
3
3-4-1 Specifications
