A.5 Drive Watt Loss Data
Table A.4 Watt Loss 200 V Class Single-Phase Models
Model Number
JZA
Heavy Duty (Carrier Frequency 8/10 kHz)
<1>
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
B0P1 0.8 4.3 7.4 11.7 1.2 5.0 8.5 13.5
B0P2 1.6 7.9 8.9 16.7 1.9 7.6 9.7 17.3
B0P4 3.0 16.1 11.5 27.7 3.2 14.6 14.4 29.1
B0P7 5.0 33.7 16.8 50.5 6.0 30.1 19.4 49.5
B1P5 8.0 54.8 25.9 80.7 9.6 51.7 29.8 81.4
<1> 10 kHz for B0P1 to B0P7
Table A.5 Watt Loss 200 V Class Three-Phase Models
Model Number
JZA
Heavy Duty (Carrier Frequency 8/10 kHz)
<1>
Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
20P1 0.8 4.3 7.3 11.6 1.2 5.0 8.0 13.0
20P2 1.6 7.9 8.8 16.7 1.9 7.6 9.5 17.1
20P4 3.0 16.2 11.5 27.7 3.5 15.8 13.6 29.4
20P7 5.0 27.4 15.9 43.3 6.0 27.5 17.2 44.7
21P5 8.0 54.8 23.8 78.6 9.6 51.7 25.8 77.5
22P2 11.0 70.7 29.9 100.6 12.0 61.3 30.4 91.7
24P0 17.5 110.5 43.3 153.8 19.6 98.7 46.3 145.0
<1> 10 kHz for 20P1 to 20P7
Table A.6 Watt Loss 400 V Class Three-Phase Models
Model Number
JZA
Heavy Duty (Carrier Frequency 8 kHz) Normal Duty (Swing PWM equal 2 kHz)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss (W)
Interior Unit
Loss (W)
Total Loss
(W)
40P2 1.2 19.2 11.5 30.7 1.2 10.0 9.6 19.6
40P4 1.8 28.9 14.8 43.7 2.1 18.5 13.9 32.4
40P7 3.4 42.3 17.9 60.2 4.1 30.5 16.8 47.3
41P5 4.8 70.7 26.2 96.9 5.4 44.5 21.8 66.3
42P2 5.5 81.0 30.7 111.7 6.9 58.5 28.4 86.9
43P0 7.2 84.6 32.9 117.5 8.8 63.7 31.4 95.1
44P0 9.2 107.2 41.5 148.7 11.1 81.7 46.0 127.7
A.5 Drive Watt Loss Data
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
167
A
Specifications
