B.3 Defaults by Drive Capacity (o2-04) and ND/HD (C6-01)
Table B.1 Single-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Settings
No. Description Unit Default Settings
− Model JZA − B0P1 B0P2 B0P4
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND
o2-04 Drive Model Selection Hex 30 31 32
− Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75
C6-02 Carrier frequency − 4 7 4 7 4 7
E2-01 Motor rated current A 0.60 1.10 1.10 1.90 1.90 3.30
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90 2.90 2.50
E2-03 Motor no-load current A 0.40 0.80 0.80 1.20 1.20 1.80
E2-05 Motor line-to-line resistance Ω 35.98 20.56 20.56 9.842 9.842 5.156
−
Momentary power loss ride-through
time
s 0.1 0.1 0.1 0.1 0.1 0.1
− Mom. power loss Baseblock time s 0.2 0.2 0.2 0.2 0.2 0.3
No. Description Unit Default Settings
− Model JZA − B0P7 B1P5
C6-01 Normal/Heavy Duty − HD HD ND
o2-04 Drive Model Selection Hex 33 34
C6-02 Carrier frequency − 4 7 3 7
E2-01 Motor rated current A 3.30 6.20 6.20 8.50
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90
E2-03 Motor no-load current A 1.80 2.80 2.80 3.00
E2-05 Motor line-to-line resistance Ω 5.156 1.997 1.997 1.601
− Momentary power loss ride-through time s 0.2 0.2 0.3 0.3
− Momentary power loss Baseblock time s 0.3 0.4 0.4 0.5
Table B.2 Three-Phase, 200 V Class Drives Default Settings by Drive Capacity and ND/HD Setting
No. Description Unit Default Settings
− Model JZA − 20P1 20P2 20P4 20P7 21P5
C6-01 Normal/Heavy Duty − HD ND HD ND HD ND HD ND HD ND
o2-04 Drive Model Selection Hex 60 61 62 63 65
− Motor rated power kW 0.1 0.2 0.2 0.4 0.4 0.75 0.75 1.1 1.5 2.2
C6-02 Carrier frequency − 4 7 4 7 4 7 4 7 3 7
E2-01 Motor rated current A 0.60 1.10 1.10 1.90 1.90 3.30 3.30 4.90 6.20 8.50
E2-02 Motor rated slip Hz 2.50 2.60 2.60 2.90 2.90 2.50 2.50 2.60 2.60 2.90
E2-03 Motor no-load current A 0.40 0.80 0.80 1.20 1.20 1.80 1.80 2.30 2.80 3.00
E2-05 Motor line-to-line resistance Ω 35.98 20.56 20.56 9.842 9.842 5.156 5.156 3.577 1.997 1.601
−
Momentary power loss ride-
through time
s 0.1 0.1 0.1 0.1 0.1 0.1 0.2 0.2 0.3 0.3
−
Momentary power loss Baseblock
time
s 0.2 0.2 0.2 0.2 0.2 0.3 0.3 0.4 0.4 0.5
No. Description Unit Default Settings
− Model JZA − 22P2 24P0
C6-01 Normal/Heavy Duty − HD ND HD ND
o2-04 Drive Model Selection Hex 66 68
− Motor rated power kW 2.2 3.0 3.7 5.5
C6-02 Carrier frequency − 3 7 3 7
E2-01 Motor rated current A 8.50 11.40 14.0 19.60
E2-02 Motor rated slip Hz 2.90 2.70 2.73 1.50
E2-03 Motor no-load current A 3.00 3.70 4.50 5.10
E2-05 Motor line-to-line resistance Ω 1.601 1.034 0.771 0.399
− Momentary power loss ride-through time s 0.5 0.5 1 1
− Momentary power loss Baseblock time s 0.5 0.5 0.6 0.7
B.3 Defaults by Drive Capacity (o2-04) and ND/HD (C6-01)
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
183
B
Parameter List
