No. Name Description Range Def. Mode
Addr.
Hex
Pg.
C6-02
Carrier Frequency
Selection
Selects the carrier frequency
1 : 2.0 kHz
2 : 5.0 kHz
3 : 8.0 kHz
4 : 10.0 kHz
5 : 12.5 kHz
6 : 15.0 kHz
7 : Swing PWM
8 to E : No setting possible
F : User defined (determined by C6-03 through C6-05)
1 to F
<57>
S 224 79
C6-03
Carrier Frequency
Upper Limit
C6-03 and C6-04 set upper and lower limits for the carrier
frequency.
carrier frequency
E1-04
max output
frequency
output frequency
× (C6-05) × K
output
frequency
C6-03
C6-04
The coefficient K depends on C6-03:
C6-03 ≥ 10.0 kHz: K = 3
10.0 kHz > C6-03 ≥ 5.0 kHz: K = 2
5.0 kHz > C6-03: K = 1
When C6-05 ≤ 6, C6-04 is disabled (makes the carrier frequency
C6-03 value).
1.0 to 15.0
<8>
O 225 80
C6-04
Carrier Frequency
Lower Limit
1.0 to 15.0
<8>
O 226 80
C6-05
Carrier Frequency
Proportional Gain
Sets the relationship of output frequency to carrier frequency when
C6-02 = F.
00 to 99
<8>
O 227 80
<8> Default setting value is dependent on parameter C6-02, Carrier Frequency Selection.
<22>
Parameter can be changed during run.
<57> Default setting value is dependent on parameter o2-04, Drive Model Selection and C6-01, Drive Duty Selection.
u
d: References
Reference parameters are used to set the various frequency reference values during operation.
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
d1: Frequency Reference
Use d1 parameters to configure the drive frequency reference.
d1-01
<22>
Frequency
Reference 1
Frequency reference
0.00 to
400.00 Hz
<19>
0.00 Hz S 280 82
d1-02
<22>
Frequency
Reference 2
Frequency reference when digital input "Multi-Step Speed
Reference 1" (H1- = 3) is on.
0.00 Hz S 281 82
d1-03
<22>
Frequency
Reference 3
Frequency reference when digital input "Multi-Step Speed
Reference 2” (H1- = 4) is on.
0.00 Hz S 282 82
d1-04
<22>
Frequency
Reference 4
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 2" (H1- = 3 and 4) are on.
0.00 Hz S 283 82
d1-05
<22>
Frequency
Reference 5
Frequency reference when digital input "Multi-Step Speed
Reference 3" (H1- = 5) is on.
0.00 Hz O 284 82
d1-06
<22>
Frequency
Reference 6
Frequency reference when digital inputs "Multi-Step Speed
Reference 1, 3 " (H1- = 3 and 5) are on.
0.00 Hz O 285 82
d1-07
<22>
Frequency
Reference 7
Frequency reference when digital inputs "Multi-Step Speed
Reference 2, 3" (H1- = 4 and 5) are on.
0.00 Hz O 286 82
d1-08
<22>
Frequency
Reference 8
Frequency reference when multi-function input "Multi-Step speed
reference 1, 2, 3" (H1- = 3, 4, 5) are on.
0.00 Hz O 287 82
d1-17
<22>
Jog Frequency
Reference
Frequency reference when digital inputs "Jog Frequency
Reference", "Forward Jog" or "Reverse Jog." are on.
6.00 Hz S 292 82
d2: Frequency Upper and Lower Limits
Use d2 parameters to configure the frequency reference limits.
d2-01
Frequency
Reference Upper
Limit
Sets the frequency reference upper limit as a percentage of
maximum
output frequency (E1-04). Output speed is limited to this
value even if the frequency reference is higher. This limit applies
to all frequency reference sources.
0.0 to 110.0 100.0% O 289 83
d2-02
Frequency
Reference Lower
Limit
Sets the frequency reference lower limit as a percentage of
maximum
output frequency (E1-04). Output speed is limited to this
value even if the frequency reference is lower. This limit applies to
all frequency reference sources.
0.0 to 110.0 0.0% O 28A 83
d3: Jump Frequency
Use d3 parameters to configure the drive Jump Frequency settings.
B.2 Parameter Table
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
173
B
Parameter List
