Omron J1000 User Manual

200 V Single Phase Units 200 V Three Phase Units
Model JZA
Rated Current [A]
Model JZA
Rated Current [A]
2 kHz 10 kHz 15 kHz 2 kHz 10 kHz 15 kHz
B0P7 6.0 5.0 4.0 20P7 6.0 5.0 4.0
Table 5.8 Drives with Heavy Duty Default Carrier Frequency of 8 kHz
200 V Single Phase Units 200 V Three Phase Units 400 V Three Phase Units
Model
JZA
Rated Current [A]
Model
JZA
Rated Current [A]
Model
JZA
Rated Current [A]
2 kHz 8 kHz 15 kHz 2 kHz 8 kHz 15 kHz 2 kHz 8 kHz 15 kHz
B1P5 9.6 8.0 6.4 — — — — 40P2 1.2 1.2 0.7
— — — — 21P5 9.6 8.0 6.4 40P4 2.1 1.8 1.1
— — — — 22P2 12.0 11.0 8.8 40P7 4.1 3.4 2.0
— — — — — — — — 41P5 5.4 4.8 2.9
— — — — 24P0 19.6 17.5 14.0 42P2 6.9 5.5 3.3
— — — — — — — — 43P0 8.8 7.2 4.3
— — — — — — — — 44P0 11.1 9.2 5.5
5.3 C: Tuning
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
81
5
Parameter Details
