42 LD Platform OEM User's Guide 11970-000 Rev H1
3.3 Unpacking
Figure 3-19. Docking Station, Mounted on Floor Plate
406 [16.0]
495 [19.5]
Units are mm [inches]
Figure 3-20. Docking Station Floor Plate Dimensions
