4 System Program
4 - 24
NA-series Programmable Terminal Hardware User’s Manual (V117)
The operation settings of the NJ/NX Troubleshooter are set from the Sysmac Studio. Double-click Trou-
bleshooter under Configurations and Setup in the Multiview Explorer. The Troubleshooter Settings
Tab Page will be displayed in the Edit Pane.
Setting the Display Languages for Errors and Event Logs
The display languages are set in the Language Mapping Area.
Operation Settings of the NJ/NX/NY Troubleshooter
No. Item Description
1 Selected Controller Selects the Controller for which to set the languages.
2 HMI Project Language Displays the project language that is set in the HMI.
3 User Event Language Sets the language to use to display user-defined events. Set the
corresponding languages for the NA project and the Controller proj-
ect.
To Next Page
