Omron NA5-12W series

4 System Program
4 - 32
NA-series Programmable Terminal Hardware User’s Manual (V117)
This screen is used to set the Ethernet port IP address and other settings for Ethernet.
This screen is used to make settings for the FTP server.
Ethernet
No. Item Description
(a) Ethernet Port 1 Settings Sets the IP address and other settings for Ethernet port 1.
(b) Ethernet Port 2 Settings Sets the IP address and other settings for Ethernet port 2. This set-
ting is ignored if you select the Ethernet Direct Connection Check
Box.
(c) Ping Test Executes a ping test for the specified address.
FTP
No. Item Description
(a) Enable FTP server Select this check box to use the FTP server.
(b) Change Account Setting Select this check box to change the account.
(c) Login Name Sets the login name.
(d) Password Sets the password.
(a) (b)
(c)
(a)
(b)
(c)
(d)
