2-16SectionSpecial Functions
258
Console function, refer to Programming Console Function in section 6 of the
Setup Manual.
Programming Console function can be used by switching to screen number
9020 even when the PC is in running mode. (Switching to screen number 9020 is
not possible by operations in the PT Status Control Area.) The PT will stop oper-
ating at the same time the Programming Console function is applied. (RUN indi-
cator goes OFF)
Pressing a Quit touch switch on the Programming Console function screen re-
turns to a screen displayed just before the Programming Console function was
called.
Reference:  When changing the screen from the PT status control area display screen, the
only screen 0 can be changed.
 The PT automatically distinguishes the model of PC that is connected and au-
tomatically displays the Programming Console function screen that conforms
to the PC.
