Omron NT21 User Manual

2-16SectionSpecial Functions
257
2-16-9 Programming Console Function
As an expansion function, the NT21, NT31/NT31C, and NT631/NT631C feature
the Programming Console function, which allows to be used in place of a
C200H-PRO27-E Programming Console.
The following table shows the combinations of communications methods and
PCs that can support the PT’s Programming Console function.
Communications
method
PC model Communications port
1:1 NT Link
C200HE-CPU42(-Z)E
*1
C200HG-CPU43/63(-Z)E
*1
C200HX-CPU44/64(-Z)E
*1
C200HX-CPU65-ZE
*1
C200HX-CPU85-ZE
*1
CPM2A-30CD-
*1
CPM2A-40CD-
*1
CPM2A-60CD-
*1
CPM2C-10-
*2
CPM2C-20-
*2
CQM1-CPU4-EV1
*1
CQM1H-CPU21/51/61
*1
SRM1-C02-V2
CPU Unit’s built-in
RS-232C port
CPM1-10CDR-
CPM1-20CDR-
CPM1-30CDR-
CPM1A-10CD-
CPM1A-20CD-
CPM1A-30CD-
CPM1A-40CD-
Peripheral port
*3
1:N NT Link CS1G-CPU42/43/44/45-E(V1)
CS1H-CPU63/64/65/66/67-E(V1)
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1D-CPU65H/67H
CJ1G-CPU44/45
CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/66H/67H
CJ1M-CPU11/12/13/21/22/23
CPU Unit’s built-in
RS-232C port
Peripheral port
*4
*1: A Programming Console connected to the peripheral port always takes priority.
When a Programming Console is connected later, the PT’s Programming
Console function will become ineffective and operations from the PT will be
disabled. Also, the PT cannot be connected through a Serial Communications
Board’s RS-232C port.
*2: It is possible to connect to the RS-232C port by connecting a CPM2C-CN111
Conversion Cable, which splits the PC’s communications connector into a
peripheral port and RS-232C port.
*3: An RS-232C cable cannot be connected directly to the peripheral port. A
CPM1-CIF01 RS-232C Adapter is required.
*4: An RS-232C cable cannot be connected directly to the peripheral port. A
CS1W-CN118 RS-232C Adapter is required.
Reference: The Programming Console function is not supported by the following CPUs:
CPM1: 5 and 6 (: 1 to 9, X, or Y)
CQM1: 3, 4, 5, and 6 (: 1 to 9, X, or Y)
C200HX/HG/HE: 5 and 6 (: 1 to 9, or X)
Most of Programming Console functions are possible, with the exception of re-
cording (storing) ladder programs on cassette tape and replaying (reading)
them.
For details on the system configuration for using the Programming Console
function, the method for connection to a PC, and how to use the Programming
