2-19SectionPT Configuration Settings
284
2-19 PT Configuration Settings
Apart from the settings of the memory switches at the PT itself, the basic opera-
tion of the PT is also determined by the PT Configuration settings made at the
Support Tool.
This section describes the settings made under PT Configuration. However,
note that the operations at the Support Tool are not described. For details on
these operations, refer to the NT-series Support Tool Version 4. for Windows
Operation Manual (V061-E1-).
2-19-1 PT Configuration Settings
There are the following PT Configuration settings.
PT Model
Set the type of PT to be connected. (Refer to 3-1 Screen Creation Procedure
(page 288).)
NT20S Compatible Mode (NT21 Only)
When you want to use screen data from an NT20S in an NT21 PT, you can set
NT20S compatible mode to improve compatibility and reduce the editing re-
quired to make the screen data and the user program compatible.
The screen data will be checked by default when screen data from the NT20S is
converted for use in a NT21 PT. Refer to Appendix C for details on the NT20S
and NT30/620 compatible modes.
NT30/620 Compatible Mode (NT31/NT31C and NT631/NT631C Only)
When you want to use screen data from an earlier PT (NT30, NT30C, NT620C,
or NT625C) in an NT31, NT31C, NT631, or NT631C, you can set NT30/620
compatible mode to improve compatibility and reduce the editing required to
make the screen data and the user program compatible.
The screen data will be checked by default when screen data from an earlier PT
(NT30, NT30C, NT620C, or NT625C) is converted for use in a V2 version of an
NT31/NT31C or NT631/NT631C PT. Refer to Appendix C for details on the
NT20S and NT30/620 compatible modes.
PC Vendor
Set the direct connection type to one of the options in the following table.
Setting Direct access type Remarks
OMRON OMRON ---
Mitsubishi_A Mitsubishi A
The special system program provided
