Appendix BCompatibility with Screen Data of Other PT Models
449
NT31-ST121/122-EV2/NT31C-ST141/142-EV2. However, there will be restrictions on functions depend-
ing on the combination. Refer to the material in Limitations of System Program/PT Combinations for the
NT31/NT31C and NT631/NT631C on page 449 before application. System program version 4.0 is only for the
NT31-ST123-EV3/NT31C-ST143-EV3 and cannot be installed in pre-version-2 hardware. Also, system
program version 3.1 or earlier cannot be installed in the NT31-ST123-EV3/NT31C-ST143-EV3.
The material in Limitations of System Program/PT Combinations for the NT31/NT31C and NT631/NT631C on
page 449 shows the relationship between hardware versions and system programs. For information on the
relationship with screen data created using the Support Tool, refer to the NT-series Support Tool for Windows
Ver. 4. Operation Manual (Cat. No. V061-E1-).
NT631/NT631C System Program
System program version 1. to version 3.1 have mutual compatibility, therefore, they can be installed and
used for the NT631-ST211-E/NT631C-ST141-E/NT631C-ST151-E,
NT631-ST211-EV1/NT631C-ST141-EV1/NT631C-ST151-EV1, and
NT631-ST211-EV2/NT631C-ST141-EV2/NT631C-ST151-EV2/NT631C-ST152-EV2. However, there
will be restrictions on functions depending on the combination. Refer to the material in Limitations of System
Program/PT Combinations for the NT31/NT31C and NT631/NT631C on page 449 before application. System
program version 4.0 is only for the NT631C-ST153-EV3 and cannot be installed in pre-version-2 hardware.
Also, system program version 3.1 or earlier cannot be installed in the NT631C-ST153-EV3.
The material in Limitations of System Program/PT Combinations for the NT31/NT31C and NT631/NT631C on
page 449 shows the relationship between hardware versions and system programs. For information on the
relationship with screen data created using the Support Tool, refer to the NT-series Support Tool for Windows
Ver. 4. Operation Manual (Cat. No. V061-E1-).
Limitations of System Program/PT Combinations for the NT31/NT31C
and NT631/NT631C
The following table shows only the relationship between the hardware and system program.
For details of the relationship with the screen data created using the Support Tool, refer to NT-series Support Tool
for Windows (Version 4.) Operation Manual (V061-E1-).
Combining a -V1 Version and Version without a -V Suffix
Software Hardware
S
NT31-ST121-E
NT31C-ST141-E
NT631-ST211-E
NT631C-ST141-E
NT631C-ST151-E
NT31-ST121-EV1
NT31C-ST141-EV1
NT631-ST211-EV1
NT631C-ST141-EV1
NT631C-ST151-EV1
System program Version 1.0
The following functions can not be used
Analogue meter
High-definition font display
Installation of system programs using Memory Unit
Connection to Mitsubishi PCs
Memory link
Window control from the host
Multiple display of window screens
Moving a window
Refer to the following table for details on new
functions supported by the -V2 versions.
The following functions can not be used
Analogue meter
High-definition font display
Connection to Mitsubishi PCs
Memory link
Window control from the host
Multiple display of window screens
Moving a window
Refer to the following table for details on new
functions supported by the -V2 versions.
* Installation of system programs using Memory Unit
is possible
System program Version 2.1
The following functions can not be used
Installation of system programs using Memory Unit
High-definition font display*
Refer to the following table for details on new
functions supported by the -V2 versions.
The new functions supported by the -V2 versions
cannot be used. Refer to the following table for details.
* The system program’s version can be checked from the System Menu.
