6 - 9
6 Analog Input Units
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
6-4 List of Settings
6
*2. The setting range of Ch Input Moving Average Time depends on the model. The setting range for each
model is as follows.
z Four-point Input Units
*1. The default value and setting range of Ch Range Setting depend on the model. The default value and set-
ting range for each NX Unit are as follows.
*2. The setting range of Ch Input Moving Average Time depends on the model. The setting range for each
model is as follows.
NX Units Setting range
NX-AD2203/AD2204/AD2603/AD2604 0 to 32000
NX-AD2208/AD2608 0 to 640
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Ch1 Enable/Disable Set to enable or disable
the channel.
FALSE: Disable
TRUE: Enable
TRUE TRUE or
FALSE
--- 5002
hex
01 hex P. 6-13
Ch2 Enable/Disable TRUE TRUE or
FALSE
--- 02 hex
Ch3 Enable/Disable TRUE TRUE or
FALSE
--- 03 hex
Ch4 Enable/Disable TRUE TRUE or
FALSE
--- 04 hex
Ch1 Range Setting Set the range.
0: 4 to 20 mA
1: 0 to 10 V
2: -10 to +10 V
3: 0 to 5 V
4: 1 to 5 V
5: 0 to 20 mA
*1 *1
--- 5003
hex
01 hex P. 6-4
Ch2 Range Setting
*1 *1
--- 02 hex
Ch3 Range Setting
*1 *1
--- 03 hex
Ch4 Range Setting
*1 *1
--- 04 hex
Ch1 Input Moving Aver-
age Time
Set the time to process
moving average.
0
*2
μs 5004
hex
01 hex P. 6-17
Ch2 Input Moving Aver-
age Time
0
*2
μs 02 hex
Ch3 Input Moving Aver-
age Time
0
*2
μs 03 hex
Ch4 Input Moving Aver-
age Time
0
*2
μs 04 hex
NX Units Default value Setting range
NX-AD3203/AD3204/AD3208 0 0
NX-AD3603/AD3604/AD3608 2 2
NX Units Setting range
NX-AD3203/AD3204/AD3603/AD3604 0 to 32000
NX-AD3208/3608 0 to 640
