Omron NX-AD series User Manual

6 Analog Input Units
6 - 10
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
z Eight-point Input Units
*1. The default value and setting range of Ch Range Setting depend on the model. The default value and set-
ting range for each NX Unit are as follows.
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Ch1 Enable/Disable Set to enable or disable
the channel.
FALSE: Disable
TRUE: Enable
TRUE TRUE or
FALSE
--- 5002
hex
01 hex P. 6-13
Ch2 Enable/Disable TRUE TRUE or
FALSE
--- 02 hex
Ch3 Enable/Disable TRUE TRUE or
FALSE
--- 03 hex
Ch4 Enable/Disable TRUE TRUE or
FALSE
--- 04 hex
Ch5 Enable/Disable TRUE TRUE or
FALSE
--- 05 hex
Ch6 Enable/Disable TRUE TRUE or
FALSE
--- 06 hex
Ch7 Enable/Disable TRUE TRUE or
FALSE
--- 07 hex
Ch8 Enable/Disable TRUE TRUE or
FALSE
--- 08 hex
Ch1 Range Setting Set the range.
0: 4 to 20 mA
1: 0 to 10 V
2: -10 to +10 V
3: 0 to 5 V
4: 1 to 5 V
5: 0 to 20 mA
*1 *1
--- 5003
hex
01 hex P. 6-4
Ch2 Range Setting
*1 *1
--- 02 hex
Ch3 Range Setting
*1 *1
--- 03 hex
Ch4 Range Setting
*1 *1
--- 04 hex
Ch5 Range Setting
*1 *1
--- 05 hex
Ch6 Range Setting
*1 *1
--- 06 hex
Ch7 Range Setting
*1 *1
--- 07 hex
Ch8 Range Setting
*1 *1
--- 08 hex
Ch1 Input Moving Aver-
age Time
Set the time to process
moving average.
0
*2
μs 5004
hex
01 hex P. 6-17
Ch2 Input Moving Aver-
age Time
0
*2
μs 02 hex
Ch3 Input Moving Aver-
age Time
0
*2
μs 03 hex
Ch4 Input Moving Aver-
age Time
0
*2
μs 04 hex
Ch5 Input Moving Aver-
age Time
0
*2
μs 05 hex
Ch6 Input Moving Aver-
age Time
0
*2
μs 06 hex
Ch7 Input Moving Aver-
age Time
0
*2
μs 07 hex
Ch8 Input Moving Aver-
age Time
0
*2
μs 08 hex
NX Units Default value Setting range
NX-AD4203/AD4204/AD4208 0 0
NX-AD4603/AD4604/AD4608 2 2
