Omron NX-AD series User Manual

6 - 19
6 Analog Input Units
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
6-5 Function
6
6-5-3 Moving Average
z Two-point Input Units
*1. The setting range of Ch Input Moving Average Time depends on the model. The setting range for each
model is as follows.
z Four-point Input Units
*1. The setting range of Ch Input Moving Average Time depends on the model. The setting range for each
model is as follows.
Setting name Description
Default
value
Setting
range
Unit
Ch1 Input Moving Aver-
age Time
Set the time to process moving average. 0
*1
μs
Ch2 Input Moving Aver-
age Time
0
*1
μs
NX Units Setting range
NX-AD2203/AD2204/AD2603/AD2604 0 to 32000
NX-AD2208/AD2608 0 to 640
Setting name Description
Default
value
Setting
range
Unit
Ch1 Input Moving Aver-
age Time
Set the time to process moving average. 0
*1
μs
Ch2 Input Moving Aver-
age Time
0
*1
μs
Ch3 Input Moving Aver-
age Time
0
*1
μs
Ch4 Input Moving Aver-
age Time
0
*1
μs
NX Units Setting range
NX-AD3203/AD3204/AD3603/AD3604 0 to 32000
NX-AD3208/AD3608 0 to 640
