Omron NX-AD series User Manual

6 Analog Input Units
6 - 20
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
z Eight-point Input Units
*1. The setting range of Ch Input Moving Average Time depends on the model. The setting range for each
model is as follows.
All Analog Input Units
Setting name Description
Default
value
Setting
range
Unit
Ch1 Input Moving Aver-
age Time
Set the time to process moving average. 0
*1
μs
Ch2 Input Moving Aver-
age Time
0
*1
μs
Ch3 Input Moving Aver-
age Time
0
*1
μs
Ch4 Input Moving Aver-
age Time
0
*1
μs
Ch5 Input Moving Aver-
age Time
0
*1
μs
Ch6 Input Moving Aver-
age Time
0
*1
μs
Ch7 Input Moving Aver-
age Time
0
*1
μs
Ch8 Input Moving Aver-
age Time
0
*1
μs
NX Units Setting range
NX-AD4203/AD4204/AD4603/AD4604 0 to 32000
NX-AD4208/AD4608 0 to 640
Target NX Units
