6 - 29

6 Analog Input Units

NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)

6-5 Function

6-5-6 User Calibration

Additional Information

• A new calibration value is reflected immediately after you write it.

• When you write a calibration value, if the voltage or current that is input to the Unit terminal

is outside the correctable range, the following message will be displayed and calibration will

fail. The following message appears in the case of a Slave Terminal.
