7 - 23

7 Analog Output Units

NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)

7-5 Functions

7-5-5 User Calibration

5 Click the Test Button to output the value of an analog signal that was calibrated in Procedure 4.

Make the calibration to correctly output the value of 0% analog signal from the terminal.

6 After you complete the calibration, click the Write Button under Lower limit settings.
