Omron NX-AD series User Manual

A - 47
Appendices
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
A-3 List of NX Objects
A
A-3-2 Analog Input Units
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5006 --- Input Over Range/Under
Range Status
--- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Ch1 Over Range Status FALSE TRUE or
FALSE
*2
--- BOOL RO Not
pos-
sible
---
02 Ch1 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
03 Ch2 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
04 Ch2 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
05 Ch3 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
06 Ch3 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
07 Ch4 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
08 Ch4 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
09 Ch5 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
0A Ch5 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
0B Ch6 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
0C Ch6 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
0D Ch7 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
0E Ch7 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
0F Ch8 Over Range Status FALSE --- BOOL RO Not
pos-
sible
---
10 Ch8 Under Range Status FALSE --- BOOL RO Not
pos-
sible
---
