Appendices
A - 50
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
These objects accept I/O allocations.
You cannot access the objects that are described below with the Read NX Unit Object instruction, Write
NX Unit Object instruction, or other messages.
*1. The default value and data range for Number of Entries are as follows.
Objects That Accept I/O Allocations
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
7000 --- Analog Output Value --- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Ch1 Analog Output Value 0 -32768 to
32767
--- INT RW Pos-
sible
N
02 Ch2 Analog Output Value 0 -32768 to
32767
--- INT RW Pos-
sible
N
03 Ch3 Analog Output Value 0 -32768 to
32767
--- INT RW Pos-
sible
N
04 Ch4 Analog Output Value 0 -32768 to
32767
--- INT RW Pos-
sible
N
NX Units Default value Data range
NX-DA2203/DA2205/DA2603/
DA2605
22
NX-DA3203/DA3205/DA3603/
DA3605
44
Other models 0 0
