Appendices
A - 52
NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)
*1. The default value and data range for Number of Entries are as follows.
*2. The default value and data range for Ch Range Setting are as follows.
Index
(hex)
Subindex
(hex)
Object name
Default
value
Data range Unit
Data
type
Acc
ess
I/O
allo-
cat-
ion
Data
attri-
bute
5011 --- Output Range Setting --- --- --- --- --- --- ---
00 Number of Entries
*1 *1
--- USINT RO Not
pos-
sible
---
01 Ch1 Range Setting
*2 *2
--- UINT RW Not
pos-
sible
Y
02 Ch2 Range Setting --- UINT RW Not
pos-
sible
Y
03 Ch3 Range Setting --- UINT RW Not
pos-
sible
Y
04 Ch4 Range Setting --- UINT RW Not
pos-
sible
Y
NX Units Default value Data range
NX-DA2203/DA2205/DA2603/
DA2605
22
NX-DA3203/DA3205/DA3603/
DA3605
44
Other models 0 0
NX Units
Set
value
Meaning Default value Data range
NX-DA2203/DA2205/DA3203/
DA3205
0 4 to 20 mA 0 0
1 0 to 10 V
2 -10 to +10 V
3 0 to 5 V
4 1 to 5 V
5 0 to 20 mA
NX-DA2603/DA2605/DA3603/
DA3605
0 4 to 20 mA 2 2
1 0 to 10 V
2 -10 to +10 V
3 0 to 5 V
4 1 to 5 V
5 0 to 20 mA
