4 Installation and Wiring

NX-series Analog I/O Units User’s Manual for Analog Input Units and Analog Output Units (W522)

4-3 Wiring the Terminals

4-3-1 Wiring to the Screwless Clamping Terminal Block

3 Bundle the wires with a cable tie and secure them to the screwless clamping terminal block.

Secure wires within the range of 30 mm from the screwless clamping terminal block.

30 mm
