5 Installation and Wiring
5 - 16
NX-series Safety Control Unit
User
’
s Manual (Z930)
3
Bundle the wires with a cable t
ie
and secure
them to th
e screwl
ess clamping term
inal block.
Secure wires within the
range o
f 30 mm from the screwless clamping terminal block
.
30
153
155
