A - 87
Appendix
NX-series Safety Control Unit User’s Manual (Z930)
A-15 Version Information
A
A-15-1 Relationship between the Unit Versions of Safety Control Units and Sysmac Studio Versions
A-15 Version Information
This section describes the compatibility between unit versions of the Safety Control Units and the ver-
sion of the Sysmac Studio, as well as the functions supported by the Sysmac Studio.
This section describes the combinations that can be used of the unit versions of the Safety Control
Units, NJ/NX-series CPU Units, and Communications Coupler Unit, and the version of the Sysmac Stu-
dio.
The following table gives the model numbers and first unit versions of the NJ/NX-series CPU Units and
Communications Coupler Units and the lowest versions of the Sysmac Studio that can be used
together.
For information on the NJ/NX-series CPU Units, Communications Coupler Units, and the Sysmac Stu-
dio, refer to applicable Unit or Sysmac Studio manual.
Refer to the user’s manual for the connected Communications Coupler Unit for the relationship
between Slave Terminal functions and versions.
A-15-1 Relationship between the Unit Versions of Safety Control Units
and Sysmac Studio Versions
Model : This is the model number of the NX Unit.
Unit version : This is the unit version of the NX Unit.
EtherCAT Communications
Coupler Unit
: This is the unit version of the NX-ECC EtherCAT Coupler
Unit that supports the NX Units.
CPU Unit : This is the unit version of the NX701-, NJ501-,
NJ301-, or NJ101- NJ/NX-series CPU Unit that
supports the EtherCAT Coupler Unit.
Sysmac Studio : This is the version of Sysmac Studio that supports the EtherCAT
Coupler Unit.
EtherNet/IP Communications
Coupler Unit
: This is the unit version of the NX-EIC202 EtherNet/IP Coupler
Unit that supports the NX Units with the specified function.
Sysmac Studio : This is the version of Sysmac Studio that supports the Ether-
Net/IP Coupler Unit.
NX Unit Corresponding unit version/version
Model
Unit
version
EtherCAT EtherNet/IP
Communications
Coupler Unit
CPU Unit
Sysmac
Studio
Communications
Coupler Unit
Sysmac
Studio
NX-SL3300
Ver.1.0
Ver.1.1
*1
*1. Some Units do not have all of the versions given in the above table. If a Unit does not have the specified
version, support is provided by the oldest available version after the specified version. Refer to the user’s
manuals for the specific Units for the relation between models and versions.
Ver.1.06 Ver.1.07 --- ---
Ver.1.1 Ver.1.10 Ver.1.0 Ver.1.10
NX-SL3500
Ver.1.0
Ver.1.2
*1
Ver.1.07 Ver.1.08 --- ---
Ver.1.1 Ver.1.10 --- ---
NX-SIH400
Ver.1.0
Ver.1.1
*1
Ver.1.06 Ver.1.07 --- ---
Ver.1.1 Ver.1.10 Ver.1.0 Ver.1.10
NX-SID800 Ver.1.0 Ver.1.07
NX-SOH200
NX-SOD400
