A - 75
Appendix
NX-series Safety Control Unit User’s Manual (Z930)
A-7 Icon list for Safety Slave Unit Parame-
ters
A
A-7-4 Contact Icons for Output Devices
A-7-4 Contact Icons for Output Devices
Category Device Settable contact icons
Relays with Forcibly
Guided Contacts
Relays with Forcibly Guided Contacts for
Dual Channel
Load Relays with Forci-
bly Guided Con-
tacts
Contactor
Relays with Forcibly Guided Contacts for
Single Channel
Load Relays with Forci-
bly Guided Con-
tacts
Contactor
Generic Device Single Channel with Test Pulse
Load Relays with Forci-
bly Guided Con-
tacts
Contactor
Single Channel without Test Pulse
Load Relays with Forci-
bly Guided Con-
tacts
Contactor
Dual Output with Test Pulse
Load Relays with Forci-
bly Guided Con-
tacts
Contactor
Dual Output without Test Pulse
Load Relays with Forci-
bly Guided Con-
tacts
Contactor
To Next Page
