7 Programming
7 - 70
NX-series Safety Control Unit User’s Manual (Z930)
5 Select Safety Simulation Pane from the View Menu.
The Safety Simulation Pane is displayed below the Toolbox Pane on the right of the window.
6 Click the Run Button in the Safety Simulation Pane. Or, select Run from the Simulation Menu.
The following Connect to safety device Dialog Box is displayed.
Note 1. It is not necessary to change the name from the current node name.
2. You do not need to enter anything in the Instance identification Box.
To Next Page
