A - 61
Appendix
NX-series Safety Control Unit User’s Manual (Z930)
A-4 Change Tracking
A
This section describes the procedures to create and delete pins, and the jump function.
Creating Pins
When you click the Pin project Button, a dialog box to enter the current status name is displayed.
The name that you set is shown as the pin information in the upper part of the Change Tracking Tab
Page.
If the data changes from the data that is in effect at this point, the contents of the change are dis-
played in the tab page.
Deleting a Pin
When you click the Clear pin Button, the status that you created with the Pin project Button is
deleted.
Jump Function
When you double-click information on the Change Tracking Tab Page, the global variable table,
FBD editor, or other corresponding tab page is displayed.
Pin Operations
