A-7 Icon list for Safety Slave Unit Parame-
ters
A
A-7-1 External Device Icons for Input Devices
Generic Device Mechanical Contact for Single Channel
Mechanical Contact for Dual Channel
Equivalent
Mechanical Contact for Dual Channel
Complementary
Semiconductor Output for Single Chan-
nel
Semiconductor Output for Dual Channel
Equivalent
Semiconductor Output for Dual Channel
Complementary
Category Device Settable external device icons
To Next Page
