2-1 System Configuration and Devices
2-1-1 Overview
Connect a Power Supply, Pushbutton Switches, and Indicators to the NX1P and create a
ladder program in Section 3 Ladder Programming.
Automation Software
Sysmac Studio
Standard Edition
Machine Automation
Controller
NX1P
Ethernet cable
(100Base-TX/10Base-T)
SYSMAC-SE200D
(DVD only)
SYSMAC-SE201L
NX1P2-□□□□ -
The physical devices such as NX1P, Pushbutton Switches, and Indicators will help you
understand programming concepts.
Even if there is no physical device, you can check operation using the Simulator in the
Sysmac Studio.
Section 4, 5, and 6 explain about simulations.
