Omron NX1P - Checking the Operation of the Program (Watch Tab Page)

60
● Checking the operation using the Simulator
1. Select Run from the Simulation Menu to start the Simulator.
2. Double-click the input. You can change the value between True (ON) and False (OFF) to
debug the programs, instead of pressing the physical switch.
3-6-5 Checking the Operation of the Program (Watch Tab Page)
You can also check the operation of the program in the Watch Tab Page.
Monitoring can be performed online on the NX1P or offline with the Simulator in the same way.
1.
Select Watch Tab Page from the View Menu. The Watch Tab Page is displayed at the
bottom of the window.
2. Click the Watch Tab Page 1 Tab.
