3-96
3-3 Servomotor Specifications
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
Encoder Specifications
Incremental Encoder Specifications
Absolute Encoder Specifications
Note: Multi-rotation Data Backup
• The multi-rotation data will be lost if the battery cable connector is disconnected at the
motor when connecting the battery cable for the absolute encoder and battery.
• If you do not use an absolute encoder battery cable and connect the battery to CN1,
the multi-rotation data will be lost if CN2 is disconnected.
Item Specifications
Encoder system Optical encoder
20 bits
Number of output
pulses
Phases A and B: 262,144 pulses/rotation
Phase Z: 1 pulse/rotation
Power supply voltage 5 VDC ± 5%
Power supply current 180 mA (max.)
Output signals +S, −S
Output interface RS-485 compliant
Item Specifications
Encoder system Optical encoder
17 bits
Number of output
pulses
Phases A and B: 32,768 pulses/rotation
Phase Z: 1 pulse/rotation
Maximum rotations −32,768 to +32,767 rotations
Power supply
voltage
5 VDC ± 5%
Power supply current 110 mA (max.)
Applicable battery
voltage
3.6 VDC
Current consumption
of battery
265 μA (for a maximum of 5 s right after power interruption)
100 μA (for operation during power interruption)
3.6 μA (when power is supplied to the Servo Drive)
Output signals +S, −S
Output interface RS-485 compliant
To Next Page
