4-56
4-4 Regenerative Energy Absorption
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
4
System Design
Servo Drive Regeneration Absorption Capacity
The following table shows the regenerative energy (and amount of regeneration) that each
Servo Drive can absorb. If these values are exceeded, take the processes above.
Regenerative energy to be absorbed by built-in capacitor varies depending on the input voltage
to the main circuit power supply for the Servo Drive. The above value for each Servo Drive
model is calculated when the input voltage is as follows.
Servo Drive model
Regenerative
energy to be absorbed
by built-in capacitor [J]
Internal regeneration
resistor
Allowable
minimum
regeneration
resistance [Ω]
Average amount of
regenerative energy to
be absorbed [W]
R88D-KTA5L 11 − 17
R88D-KT01L 11 − 17
R88D-KT02L 15 − 17
R88D-KT04L 22 17 13
R88D-KT01H 18 − 34
R88D-KT02H 18 − 34
R88D-KT04H 26 − 34
R88D-KT08H 46 12 25
R88D-KT10H 74 18 25
R88D-KT15H 74 18 25
R88D-KT20H 74 72 10
R88D-KT30H 113 60 7
R88D-KT50H 113 60 5
R88D-KT75H 282 − 4
R88D-KT150H 254 − 4
R88D-KT06F 64 21 100
R88D-KT10F 64 21 100
R88D-KT15F 64 21 100
R88D-KT20F 64 29 40
R88D-KT30F 106 60 40
R88D-KT50F 106 60 29
R88D-KT75F 273 − 14
R88D-KT150F 492 − 14
Model Main circuit power supply input voltage
R88D-K@@L 100 VAC
R88D-K@@H 200 VAC
R88D-K@@F 400 VAC
