Omron OMNUC G5 R88D-KT50F User Manual

3-125
3-4 Cable and Connector Specifications
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
XW2B-50G5 (M3.5 Screw Terminal Block)
 Dimensions
 When using crimp terminals, use crimp terminals with the following dimensions.
 When connecting wires and crimp terminals to a terminal block, tighten them with a tightening
torque of 0.59 N•m.
Applicable crimp terminals Applicable wires
Round terminals
1.25−3
AWG22-16
(0.3 to 1.25 mm
2
)
2−3.5
AWG16-14
(1.25 to 2.0 mm
2
)
Fork terminals
1.25Y−3
AWG22-16
(0.3 to 1.25 mm
2
)
2−3.5
AWG16-14
(1.25 to 2.0 mm
2
)
Flat cable connector (MIL type plug)
3.5
15.5
45
2-φ3.5
7
Terminal
block
7.3
8.5
7
29.5
3.5
(45.3)
43.5
20.5
247.5
Round terminal Fork terminal
3.7mm
6.8 mm max.6.8 mm max.
φ3.2mm
