Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 22
Figure 8: Dimension of TM5X-900
*All measures are in mm.
4.2.1.2 Robot Assembly Diagram
Shown below is an illustration of the robot components. To avoid safety risks, do not attempt to
disassemble any component on your own. Contact your local corporation support for any service
request.
