Omron Regular Payload Series

Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 67
Figure 65: Detachable I/O Panel
NOTE:
The control box comes with the IP32 rating, but the Corporation does not guarantee this rating for
disassembling detachable I/O panel from its original location.
screw
screw
