Figure 25: References of TM5-700/ TM5M-700/ TM5-900 / TM5M-900 End Module Components
GRIPPER Button
Camera module
Flange (ISO 9409-1-50-4-M6)
Digital I/O
Indication Light Ring
Analog I/O
FREE Button
VISION Button
POINT Button
TM5-700/ TM5M-700/ TM5-900 / TM5M-900 End Module Components
Light module
