2-2 Molded-case Circuit Breaker (MCCB)
Be sure to connect MCCBs between power supply and SYSDRIVE 3G3IV
input terminals L1 (R), L2 (S), L3 (T). Recommended MCCBs are listed in the
table below.
When a ground fault interrupter is used, select the one with no influence for
high frequency, and setting current should be 200mA or over and operating
time, 0.1 s or over to prevent malfunction.
Molded-case Circuit Breakers and Magnetic Contactors
SYSDRIVE Molded-case circuit
breaker or fuse
Model 3G3IV Capacity Rated output
current
Rated current
200 to 230V A2004-
1.4 3.2 6A
A2007-
2.1 4.8 10 A
A2015-
2.7 6.4 20 A
A2022-
4.1 9.6 20 A
A2037-
6.9 16 30 A
A2055-
10.3 24 50 A
A2075-
13.7 32 60 A
B2110-
20.6 48 100 A
B2150-
27.4 64 100 A
B2185-
34 80 150 A
B2220-
41 96 150 A
B2300-
54 130 225 A
B2370-
68 160 225 A
B2450-
78 183 300 A
B2550-
95 224 400 A
B2750-
130 300 600 A
400 to 460 V A4004-
1.4 1.6 5A
A4007-
2.2 2.6 5A
A4015-
3.4 4.0 10 A
A4022-
4.1 4.8 10 A
A4037-
6.9 8 20 A
A4055-
10.3 12 20 A
A4075-
13.7 16 30 A
B4110-
20.6 24 50 A
B4150-
27.4 32 60 A
B4185-
34 40 80 A
B4220-
41 48 100 A
B4300-
54 64 100 A
B4370-
68 80 150 A
B4450-
82 96 150 A
B4550-
110 128 225 A
B4750-
140 165 300 A
B411K-
200 224 400 A
Section 2-2
